TYA-I Phosphate ester fire resistant hydraulic oil purifier machine
Application:
Series TYA-I Fire-resistance Oil Filtration Plant is specially designed for regeneration of the fire-resistant hydraulic oil and EH phosphate ester fire-resistant oil from the speed control system of 300,000KW’s generator sets and above. It is also suitable for other hydraulic systems using phosphate ester fire-resistant fuel as the working medium.
Features:
1.High Efficiency Acid Removal and Dehydration.
2.Equips with a new and efficient regeneration system and dehydration chamber, which can quickly reduce the acid value and moisture of the fire-resistant oil, increase its resistivity, and restore the physical and chemical properties of the oil.
3.Cleanliness up to NAS grade 5.
4.The tank and pipelines where fire-resistant oil going through are all made of 304 stainless steel, Anti-acid and corrosion resistance type sealing, filter elements.
5.Compact structure and easy operation.
Technical Parameters
| Item | Parameter | Type Unit | TYA-I-10 | TYA-I-20 | TYA-I-30 | TYA-I-50 | |
| Technical Parameter | Flow Rate | L/MIN | 10 | 20 | 30 | 50 | |
| Working Vacuity | Mpa | -0.09 | |||||
| Working pressure | Mpa | ≤0.5 | |||||
| Temperature Range | °C | 45-65 | |||||
| Power Supply | 50Hz 380V 3-Phase 4-Wire (or as requested) | ||||||
| Total Power | KW | 10 | 12 | 13.5 | 33 | ||
| Inlet/Outlet Diameter | mm | 32 | 48 | ||||
| Size | Length | mm | 1200 | 1200 | 1200 | 1600 | |
| Width | mm | 940 | 960 | 1000 | 1200 | ||
| Height | mm | 1550 | 1550 | 1600 | 2000 | ||
| Weight | Kg | 380 | 400 | 420 | 500 | ||
Water Content | ppm | ≤50 |
Filtering Accuracy | µm | ≤1 |
Cleanliness | NAS | ≤NAS 1638 Grade 5 |
Acid Value | Mg KOH/g | ≤0.03 |
Resistivity | cm | ≥6×109 (DL/T 421) |
